Ultima Selectronic Concealed Toilet Flush Valve with Wall Box, Base Model, Piston-Type, 1.28 gpf/4.8 Lpf

• Self-Cleaning Piston with integral wiper spring significantly reduces clogging and maintenance• Selectronic® Proximity System with universal sensor provides hygienic, "hands free" operation• State-of-the-Art Electronics prevent ghost flushing• Dezincification Resistant semi-red brass alloy• Fully Mechanical Manual Override Button can flush the valve without power• Fail-Safe: Valve automatically closes upon loss of power or water pressure and does not need to be reset• Adjustable Sanitary Flush cleans the fixture & maintains the trap seal.• Chemical resistant EPDM Seals for extended life• Adjustable tailpiece for rough-in flexibility• Can be installed left or right handed• All exposed parts are chrome-plated SustainabilityCEC Listed• CALGreen Compliant

Features
  • For flushometer bowls with 1-1/2" (38 mm) exposed back spud
  • POWER KIT MUST BE PURCHASED SEPARATELY
  • FOR INSTALLATIONS WITH FRONT ACCESS
  • Includes Wall Box with Vandal-Resistant Brushed S.S. Cover
  • Touchless operation limits the spread of germs
  • Exclusive DynaClean® self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • Fully mechanical manual override can operate without power
  • Proprietary brass alloy resists dezincification
  • 1.28 gpf/4.8 Lpf
Technical Features
  • For floor-mount flushometer bowls with 1-1/2" (38 mm) exposed back spud
  • POWER KIT MUST BE PURCHASED SEPARATELY
  • FOR INSTALLATIONS WITH FRONT ACCESS
  • Includes Wall Box with Vandal-Resistant Brushed S.S. Cover
  • Touchless operation limits the spread of germs
  • Exclusive DynaClean® self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • Fully mechanical manual override can operate without power
  • Proprietary brass alloy resists dezincification
  • 1.28 gpf/4.8 Lpf
Description
Net Weight
SKU
Color
List Price USD
Ultima Selectronic Concealed Toilet Flush Valve with Wall Box, Base Model, Piston-Type, 1.28 gpf/4.8 Lpf
20 lb (9.1 kg)
No Finish (007)
1271
Required Components (Not Included)
Selectronic® CR-P2 Lithium Power Kit
0 lb (0.2 kg)
No Finish
46
spacer
Selectronic® PWRX Power Kit
0 lb (0.2 kg)
No Finish
172
spacer
Selectronic® Hard Wired AC Power Kit
1 lb (0.3 kg)
No Finish
140
spacer
Selectronic® Multi-AC Power Kit
0 lb (0.1 kg)
No Finish
83
spacer
Selectronic® Plug-In AC Power Kit
1 lb (0.4 kg)
No Finish
109
Optional Components (Not Included)
Selectronic® Battery Back-Up Kit
0 lb (0.1 kg)
No Finish
110
ADA Compliant: Yes
Barrier Free: Yes
Brand: American Standard
Cal Green: Yes
Category: Flush Valves and Sanitary Items
Color / Finish: No Finish
Collections: Selectronic
WaterSense: Yes
Touchless: Touchless
Gallons Per Flush (min-max): 1.28 GPF
Number of Output Valves: 1
Height: 624
Length: 388
Width: 404
Residential or Commercial: Commercial
Subcategory: Sensor Flush Valve and Sanitary Items
Water Efficient: Yes
