Triple Function Thermostatic Valve Trim

The Grohtherm SmartControl Triple Function Thermostatic Trim from GROHE is a slim, contemporary design that will enhance any bathroom and make showering more enjoyable. Innovative and intuitive to use, the triple-function SmartControl lets you adjust water volume for up to three spray sources with the simple push-turn of a button. Easily switch between sprays, experience each spray individually or enjoy all three at the same time. It features integrated GROHE Turbostat technology to keep water temperature consistent for the duration of your shower, preventing any unpleasant hot/cold fluctuations. Please note that this product must be installed in combination with the GROHE Rapido SmartBox (35601000).

Features
  • GROHE SmartControl is easy to use: push for on/off, turn for volume adjustment
  • GROHE EcoJoy uses less water without sacrificing performance
  • GROHE LongLife finish
  • GROHE SafeStop override button allows you to set a maximum temperature of 100° F/38° C to prevent scalding
  • GROHE QuickFix installation system requires fewer, less complicated parts to reduce installation time by as much as 50%
  • Includes optional flow reducer to conserve water
  • Includes icons to customize push buttons: hand shower, shower head, body spray, bath filler
  • Limited lifetime warranty
Technical Features
  • GROHE LongLife finish
  • GROHE SmartControl: push for ON-OFF, turn for volume adjustment from EcoJoy to Full Flow, exchangeable symbols
  • GROHE TurboStat compact 3/4" cartridge with wax thermo element
  • GROHE SafeStop safety button with manual override at 100°F/38°C
  • GROHE SafeStop Plus temperature limiter at 115° F/46° C
  • Multiple outlets can be run simultaneously
  • 6 1/4" Metal wall escutcheon with GROHE QuickFix
  • 3/8" Thin profile escutcheon
  • Wall plate is angle adjustable up to 6°
  • Optional flow reducer for CALGreen compliance included (Note: Cannot be used for shower systems that include tub spout),Built-in check valve with dirt strainer,Includes icons to customize push buttons: Hand Shower, Showerhead, Bath Filler, Showerhead (2nd Spray), Showerhead (3rd Spray) & Body Spray,Includes service stops,Maximum combined flow performance: 9.5gpm (36L/min) @ 43.5psi (3 bar),Requires Grohtherm Rapido SmartBox (35 601) (sold separately)
Nominal Dimensions: 1-11/16 in x 6-1/4 in x 6-1/4 in (43 mm x 159 mm x 159 mm)
Description
Net Weight
SKU
Color
List Price USD
Triple Function Thermostatic Valve Trim
3 lb (1.5 kg)
Brushed Nickel (GEN)
1246
Chrome (G00)
923
Matte Black (243)
1246
Hard Graphite (GA0)
1339
Brushed Cool Sunrise (GGN)
1339
Required Components (Not Included)
Universal Rough-In Box
4 lb (1.8 kg)
No Finish
194
Optional Components (Not Included)
SmartControl Icon Caps
0 lb (0.0 kg)
Frosted Granite
53
Brand: GROHE
Category: Thermostats
Color / Finish: Brushed Nickel
Collections: Grohtherm® SmartControl
Handle Type: Push Button
Fitting Material: Metal
Fixture or Fitting Material: Metal
Kitchen or Bathroom: Bath
LIXIL Select: Yes
Height: 6-1/4
Length: 1-11/16
Width: 6-1/4
Residential or Commercial: Residential
Subcategory: Thermostats Trim
Valve Type: Thermostatic Valves
Warranty: Limited Lifetime Warranty
