Grohtherm® SmartControl

Single Function Thermostatic Valve Trim

The Grohtherm SmartControl Single Function Thermostatic Trim from GROHE is a slim, contemporary design that will enhance any bathroom. This innovative, single-function SmartControl allows you to adjust water volume from one spray source with the simple push-turn of a button. It features integrated GROHE Turbostat technology to keep water temperature consistent for the duration of your shower, preventing any unpleasant hot/cold fluctuations. Please note that this product must be installed in combination with the GROHE Rapido SmartBox (35601000).

Chrome 29140000 DISCONTINUED
List Price: $785.00
Enjoy More Rewards LIXIL Select
Items REQUIRED for Install
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • GROHE SmartControl is easy and intuitive: push for on/off, turn for volume adjustment
  • GROHE LongLife finish
  • GROHE SafeStop override button allows you to set a maximum temperature of 100° F/38° C to prevent scalding
  • GROHE QuickFix installation system requires fewer, less complicated parts to reduce installation time by as much as 50%
  • Includes optional flow reducer to conserve water and icons to customize button
  • Limited lifetime warranty
Technical Features
  • GROHE LongLife finish
  • GROHE SmartControl: push for ON-OFF, turn for volume adjustment from EcoJoy to Full Flow, exchangeable symbols
  • GROHE TurboStat compact 3/4" cartridge with wax thermo element
  • GROHE SafeStop safety button with manual override at 100°F/38°C
  • GROHE SafeStop Plus temperature limiter at 115° F/46° C
  • 6 1/4" Metal wall escutcheon with GROHE QuickFix
  • 3/8" Thin profile escutcheon
  • Wall plate is angle adjustable up to 6°
  • Optional flow reducer for CALGreen compliance included
  • Built-in check valve with dirt strainer,Includes icons to customize push buttons: Hand Shower, Showerhead & Bath Filler,Includes service stops,Maximum flow performance: 7.7gpm (29L/min) @ 43.5psi (3 bar),Requires Grohtherm Rapido SmartBox (35 601) (sold separately)
Nominal Dimensions: 1-11/16 in x 6-1/4 in x 6-1/4 in (43 mm x 159 mm x 159 mm)
Description
Net Weight
SKU
Color
List Price USD
Single Function Thermostatic Valve Trim
4 lb (1.7 kg)
29140000
Chrome (G00)
785
291402430
Matte Black (243)
1061
29140A00
Hard Graphite (GA0)
1139
29140EN0
Brushed Nickel (GEN)
1061
29140GN0
Brushed Cool Sunrise (GGN)
1139
Required Components (Not Included)
Universal Rough-In Box
4 lb (1.8 kg)
35601000
No Finish
194
Optional Components (Not Included)
SmartControl Icon Caps
0 lb (0.0 kg)
14077XH0
Frosted Granite
53
Download Specification Sheet
Brand: GROHE
Category: Thermostats
Color / Finish: Chrome
Collections: Grohtherm® SmartControl
Handle Type: Push Button
Fitting Material: Metal
Fixture or Fitting Material: Metal
Kitchen or Bathroom: Bath
LIXIL Select: Yes
Height: 6-1/4
Length: 1-11/16
Width: 6-1/4
Residential or Commercial: Residential
Subcategory: Thermostats Trim
Valve Type: Thermostatic Valves
Warranty: Limited Lifetime Warranty
Download All Supporting Documents

Specification Sheet

Installation Instructions

Installation Instructions

Replacement Parts
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
2D CAD Files
.dwg icon 2D CAD File
.dxf icon 2D CAD File
3D CAD Files
.dxf icon 3D CAD File
REVIT Files
.rfa icon REVIT File
3D Objects are not currently available for this product
