Selectronic

Ultima Selectronic Touchless Urinal Flush Valve, Piston-Type, Battery, 1.0 gpf/3.8 Lpf, 1-1/4-inch

The Selectronic Urinal Flush Valves feature a self-cleaning piston design that saves time and money by eliminating routine maintenance and preventing the valve from running due to clogs.  The Selectronic flush valves include a pressure compensation feature that maintains the proper flush volume regardless of inlet water pressure.Features

Chrome 6062601.002 DISCONTINUED
List Price: $633.00
ADA Compliant
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • For urinals with 1-1/4-inch (32 mm) exposed top spud
  • 8-year CR-P2 lithium battery installed in valve
  • Touchless operation limits the spread of germs
  • Exclusive DynaClean® self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • Fully mechanical manual override can operate without power
  • Fail-Safe operation: Valve automatically closes upon loss of power or water pressure
  • Pressure Compensation feature ensures accurate flush volume regardless of inlet water pressure
  • Proprietary brass alloy resists dezincification
  • 11-1/2" (292 mm) rough-in
Technical Features
  • For urinals with 1-1/4-inch (32 mm) exposed top spud
  • Includes CR-P2 lithium battery with 4 year life (assuming 4,000 uses per month)
  • Touchless operation limits the spread of germs
  • Exclusive DynaClean® self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • Fully mechanical manual override can operate without power
  • Fail-Safe operation: Valve automatically closes upon loss of power or water pressure
  • Pressure Compensation feature ensures accurate flush volume regardless of inlet water pressure
  • Proprietary brass alloy resists dezincification
  • 11-1/2" (292 mm) rough-in
Description
Net Weight
SKU
Color
List Price USD
Ultima Selectronic Touchless Urinal Flush Valve, Piston-Type, Battery, 1.0 gpf/3.8 Lpf, 1-1/4-inch
8 lb (3.7 kg)
6062601.002
Chrome (002)
633
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Batteries Included: Yes
Batteries Required: Yes
Brand: American Standard
Category: Flush Valves and Sanitary Items
Color / Finish: Chrome
Flush Value: Exposed
Collections: Selectronic
Fitting Connection Size Input: 25.40
Fitting Material: Brass
Touchless: Touchless
Fixture or Fitting Material: Brass
Gallons Per Flush (min-max): 1 GPF
Input Connection Type: NPT (National Pipe Tapered Threads)
Number of Output Valves: 1
Height: 16
Height: 16
Length: 4-1/2
Residential or Commercial: Commercial
Rough In Size: 11.5
Subcategory: Sensor Flush Valve and Sanitary Items
Warranty: 5 Year Limited Warranty
Download All Supporting Documents

Specification Sheet

Installation Instructions
