Afwall

Afwall® Millennium® 1.1 – 1.6 gpf (4.2 – 6.0 Lpf) Back Spud Elongated Wall-Hung EverClean® Bowl With Bedpan Lugs

The High Efficiency, Low Consumption Afwall Millennium Back Spud Elongated Toilet bowl can be used with 1.1 – 1.6 gpf flush valves and achieves a MaP score of 1,000 grams. Features our EverClean® antimicrobial surface to protect against mold, mildew, odor- and stain-causing bacteria. Perfect for commercial installations, the elongated bowl is designed to be water efficient and can be used for ADA applications.

White 3354101.020 FUTURE DISCONTINUATION   Substitution Available (3352101.020)
List Price: $450.00
ADA Compliant Cal Green Environmental Product Declaration Everclean WaterSense
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Wall-hung elongated flushometer bowl, less seat
  • High Efficiency Toilet (HET) operates in the range of 1.1 gpf – 1.6 gpf (4.2 Lpf – 6.0 Lpf)
  • Maximum Performance (MaP) score of 1,000 grams at 1.1 – 1.6 gpf
  • Antimicrobial surface: EverClean® protects against mold, mildew, odor- and stain-causing bacteria
  • Direct-fed siphon jet flush action
  • 2-1/8" (54 mm) fully-glazed trapway – 2" (51 mm) minimum ballpass
  • Static weight load of 1,000 lbs (453 kg). Not recommnded for bariatric use.
  • Concealed trapway design with condensation channel
  • 1-1/2" (38 mm) inlet spud
  • With bedpan lugs
Technical Features
  • Wall-hung elongated flushometer bowl, less seat
  • High Efficiency Toilet (HET) operates in the range of 1.1 gpf – 1.6 gpf (4.2 Lpf – 6.0 Lpf)
  • Maximum Performance (MaP) score of 1,000 grams at 1.1 – 1.6 gpf
  • EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria
  • Direct-fed siphon jet flush action
  • 2-1/8" (54 mm) fully-glazed trapway – 2" (51 mm) minimum ballpass
  • Static weight load of 1,000 lbs (453 kg). Not recommnded for bariatric use.
  • Concealed trapway design with condensation channel
  • 1-1/2" (38 mm) inlet spud
  • With bedpan lugs
Nominal Dimensions: 26 in x 14 in x 15 in (660 mm x 356 mm x 381 mm)
Description
Net Weight
SKU
Color
List Price USD
Afwall® Millennium® 1.1 – 1.6 gpf (4.2 – 6.0 Lpf) Back Spud Elongated Wall-Hung EverClean® Bowl With Bedpan Lugs
53 lb (24.2 kg)
3354101.020
White (020)
450
Optional Components (Not Included)
Commercial Heavy Duty Open Front Elongated Toilet Seat
3 lb (1.4 kg)
5901100.020
White
46
spacer
Commercial Heavy Duty Open Front Elongated Toilet Seat With EverClean® Surface
3 lb (1.3 kg)
5901110T.020
White
57
Substitutions
Afwall® Millennium® 1.1 – 1.6 gpf (4.2 – 6.0 Lpf) Top Spud Elongated Wall-Hung EverClean® Bowl With Bedpan Lugs
52 lb (23.6 kg)
3352101.020
White
243
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Front to Back Length: 13-1/8
Bowl Shape: Elongated
Brand: American Standard
Cal Green: Yes
Category: Commercial Toilet
Chair Height: Standard
Color / Finish: White
Collections: Afwall
WaterSense: Yes
Everclean: Yes
Fixture Material: Vitreous China
Fixture or Fitting Material: Vitreous China
Flush Technology: Flushometer
Gallons Per Flush (min-max): 1.1 - 1.6 GPF
MAP Performance Rating: 1000
Height: 15
Height: 15
Length: 26
Length: 26
Width: 14
Residential or Commercial: Commercial
Subcategory: Wall Hung Commercial Toilet
Toilet Mount Type: Wall Mount
Trapway Diameter: 2-1/8
Toilet Type: Wall_Hung_Toilet_Bowl
Warranty: 1 Year Limited Warranty
Download All Supporting Documents

Specification Sheet

Installation Instructions

Environmental Product Declaration
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
There are no videos currently available for this product
3D Objects are not currently available for this product
