Vormax

Townsend® VorMax® One-Piece 1.28 gpf/4.8 Lpf Chair Height Right-Hand Trip Lever Elongated Toilet With Seat

The revolutionary design of the Townsend VorMax Right Height Elongated One-Piece Toilet blends style and functionality for an architecturally inspired piece with leading innovations. Featuring superior flushing technology, the VorMax siphon action flush powerfully rinses the bowl with every flush. Along with the CleanCurve® Rim and EverClean® antimicrobial surface to protect against mold, mildew, odor- and stain-causing bacteria, your toilet will stay cleaner, longer. Designed to coordinate beautifully with the Townsend Collection, the Townsend VorMax Elongated toilet is the perfect addition to complete your contemporary bathroom.

White 2922A105.020 DISCONTINUED
List Price: $894.00
ADA Compliant CEC Certified WaterSense Everclean
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • VorMax flushing technology cleans two times\nbetter than conventional toilets
  • Chair Height elongated siphon action bowl
  • High efficiency, ultra-low consumption\n(1.28 gpf/4.8 Lpf), utilizes 20% less water
  • Antimicrobial surface: EverClean® protects against mold, mildew, odor- and stain-causing bacteria on the toilet
  • CleanCurve rim eliminates rim area where\ndirt and build-up hide
  • Dual injection flush valves
  • Includes slow-close seat and cover
  • Includes EZ-Install Tools
  • Two color-matched bolt caps
Technical Features
  • VorMax® flushing technology cleans two times better than conventional toilets*
  • 12" (305 mm) rough-in
  • Chair Height elongated siphon action bowl
  • High efficiency, ultra-low consumption (1.28 gpf/4.8 Lpf), utilizes 20% less water
  • Meets EPA WaterSense® criteria
  • EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria
  • CleanCurve® rim eliminates rim area where dirt and build-up hide
  • 16-1/2" (419 mm) rim height for accessible applications
  • 2-1/16" (52 mm) trapway
  • Dual injection flush valves,Includes slow-close seat and cover,Two color-matched bolt caps,10-year warranty,Design coordinates with Townsend® suite,trip lever on right-hand side
Nominal Dimensions: 29-1/2 in x 16-7/8 in x 29-3/4 in (749 mm x 429 mm x 756 mm)
Description
Net Weight
SKU
Color
List Price USD
Townsend® VorMax® One-Piece 1.28 gpf/4.8 Lpf Chair Height Right-Hand Trip Lever Elongated Toilet With Seat
101 lb (45.8 kg)
2922A105.020 *
White (020)
894
Separate Components
Contemporary Slow-Close & Easy Lift-Off Elongated Toilet Seat for VorMax® CleanCurve® Style Rims
4 lb (1.7 kg)
5055A65C.020
White
128
spacer
Townsend® VorMax® One-Piece Toilet Tank Cover
8 lb (3.5 kg)
735212-400.020
White
121


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Front to Back Length: 16-1/2
Bowl Included: Yes
Bowl Shape: Elongated
Brand: American Standard
Category: Toilets
CEC Certified: Yes
Chair Height: Chair
Color / Finish: White
Collections: Vormax
WaterSense: Yes
Everclean: Yes
Fixture Material: Vitreous China
Fixture or Fitting Material: Vitreous China
Flush Technology: Gravity Fed
Flush Valve Size: 3
Flusing Type: Single Flush
Gallons Per Flush (min-max): 1.28 GPF
Handle Finish: CHROME
MAP Performance Rating: 1000
Number of Batteries Included: Not Applicable (N/A)
Number of Flush Valves: 2
Height: 29-3/4
Length: 29-1/2
Width: 16-7/8
Residential or Commercial: Residential
Rough In Size: 12
Rough In Valve Included: Yes
Subcategory: Floor Standing Toilets
Tank Included: Yes
Trip Lever Location: Right Front
Bowl Height With Seat: 18-9/16
Toilet Water Efficiency: Ultra Height Efficiency Toilet
Toilet Mount Type: Floor Mount
Toilet Seat Type: Closed
Seat Included: Yes
Trapway Diameter: 2-1/16
Toilet Type: One Piece
Warranty: 10 Year Limited Warranty
Download All Supporting Documents

Specification Sheet

Installation Instructions

Replacement Parts
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
There are no videos currently available for this product
