Features
- TRADE EXCLUSIVE
- 1,000 MAP SCORE – Achieves highest rating possible for flush performance
- 12-INCH ROUGH-IN
- Antimicrobial surface: EverClean® protects against mold, mildew, odor- and stain-causing bacteria on the toilet
- WATERSENSE® CERTIFIED — Uses 20 percent less water and performs as well as or better than regular toilets
- CHAIR-HEIGHT COMFORT — Measures 17” tall, including seat, for ease of use compared to standard height. Slight variation in height may occur based on the height of the seat used.
- ADA COMPLIANT — Meets Americans with Disabilities Act requirements for use and accessibility
- LESS SEAT - Toilet seat is sold separately
- ROBUST METAL - Trip lever and shank fill valve made of durable metal
- FINISHING TOUCHES - Includes Chrome finish toilet handle and color-matched bowl caps\n,DURABLE CONSTRUCTION — Made from quality vitreous china for strength and reliability
Technical Features
- Combination bowl and tank, less seat
- High efficiency, ultra-low consumption (1.28 gpf/4.8 Lpf), utilizes 20% less water
- Meets EPA WaterSense® criteria
- Trade specific tank
- PowerWash® rim scrubs bowl with each flush
- Metal trip lever
- Metal shank fill valve
- Includes EZ-Install Tools
- EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria
- 4" (102 mm) piston-action Accelerator flush valve,2-3/8" (60 mm) fully-glazed trapway,16-1/2" (419 mm) rim height for accessible applications,12" (305 mm) rough-in,10-year warranty,Design coordinates with Retrospect® console table and pedestal sink
Nominal Dimensions: 30-1/4 in x 19-3/4 in x 31-1/2 in (768 mm x 502 mm x 800 mm)
Retrospect Champion PRO Two-Piece 1.28 gpf/4.8 Lpf Chair Height Elongated Toilet Less Seat
1 lb (0.4 kg)
White (020)
652
Linen (222)
0
Champion® PRO Chair Height Elongated Bowl
57 lb (25.9 kg)
White
330
spacer
Retrospect® Champion® PRO 1.28 gpf/4.8 Lpf 12-Inch Rough Tank
32 lb (14.7 kg)
White
322
spacer
Retrospect® Champion® PRO 12-Inch Rough Toilet Tank Cover
9 lb (4.2 kg)
White
105
Traditional Slow-Close & Easy Lift-Off Elongated Toilet Seat
7 lb (3.0 kg)
White
155
spacer
Champion® Slow-Close & Easy Lift-Off Elongated Toilet Seat
4 lb (1.6 kg)
White
116
Retrospect Champion PRO Two-Piece 1.28 gpf/4.8 Lpf Chair Height Elongated Toilet Less Seat
1 lb (0.4 kg)
White (020)
652
Linen (222)
0
Champion® PRO Chair Height Elongated Bowl
57 lb (25.9 kg)
White
330
spacer
Retrospect® Champion® PRO 1.28 gpf/4.8 Lpf 12-Inch Rough Tank
32 lb (14.7 kg)
White
322
spacer
Retrospect® Champion® PRO 12-Inch Rough Toilet Tank Cover
9 lb (4.2 kg)
White
105
Traditional Slow-Close & Easy Lift-Off Elongated Toilet Seat
7 lb (3.0 kg)
White
155
spacer
Champion® Slow-Close & Easy Lift-Off Elongated Toilet Seat
4 lb (1.6 kg)
White
116
Models marked with * are discontinued, but product may still be available while supplies last.
Didn't find the PDF or file you were looking for? Reach out to our team via our
Contact Form.
3D Objects are not currently available for this product
