Features
- DUAL FLUSH FOR WATER SAVINGS: Choose conserving 0.92 gpf/3.5Lpf or a full 1.28gpf/4.8Lpf, both offering the power to effectively clear the bowl
- DEPENDABLE PUSH-BUTTON OPERATION: Chrome actuator located on the lid makes it easy to choose the appropriate flush
- IMPRESSIVE PERFORMANCE: Offers a powerful flush and water savings, in addition to the highest MaP (Maximum Performance) score of 1,000 grams, and WaterSense® certification
- Antimicrobial surface: EverClean® protects against mold, mildew, odor- and stain-causing bacteria on the toilet
- CHAIR-HEIGHT BOWL: 16 1/2-in. high makes accessibility, sitting and standing easier and more comfortable
- EVERY FLUSH CLEANS THE BOWL: A forceful rush of water from the PowerWash® rim helps to scrub the bowl with every flush
- INCLUDES: Chrome push-button actuator on lid and color-matched bolt caps
- SEAT IS SOLD SEPARATELY: Compatible with elongated toilet set
- Dual flush 0.92/1.28 gpf H2Option for maximum water savings
Technical Features
- Siphonic action dual flush combination bowl and tank, less seat
- High efficiency, low consumption, full flush (1.28 gpf/4.8 Lpf), conserving flush (0.92 gpf/3.5 Lpf)
- Meets EPA WaterSense® and MaP PREMIUM criteria
- 16-1/2" (419 mm) rim height
- 12" (305 mm) rough-in
- EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria
- PowerWash® rim scrubs bowl with each flush
- 9" x 8" (229 x 203 mm) water surface area
- Chrome plated top-mounted push button actuator
- Sanitary dam on bowl,2" (51 mm) fully glazed trapway,Two color-matched bolt caps,Five-year warranty
Nominal Dimensions: 29-3/4 in x 15 in x 31-1/2 in (756 mm x 381 mm x 800 mm)
H2Option® Two-Piece Dual Flush 1.28 gpf/4.8 Lpf and 0.92 gpf/3.5 Lpf Chair Height Elongated Toilet Less Seat
1 lb (0.4 kg)
Bone (021)
0
White (020)
555
Linen (222)
0
H2Option® and H2Optimum® Chair Height Elongated Bowl
45 lb (20.6 kg)
White
271
Bone
383
spacer
H2Option® Dual Flush 1.28 gpf/4.8 Lpf and 0.92 gpf/3.5 Lpf 12-Inch Rough Tank
27 lb (12.2 kg)
White
284
Bone
439
spacer
H2Option® Dual Flush 1.28 gpf/4.8 Lpf and 0.92 gpf/3.5 Lpf 12-Inch Rough Lined Tank
27 lb (12.2 kg)
White
317
spacer
H2Option® Dual Flush 12-Inch Rough Toilet Tank Cover
7 lb (3.3 kg)
White
83
Bone
96
Cardiff Slow-Close Elongated Toilet Seat
3 lb (1.5 kg)
White
85
Bone
92
H2Option® Two-Piece Dual Flush 1.28 gpf/4.8 Lpf and 0.92 gpf/3.5 Lpf Chair Height Elongated Toilet Less Seat
1 lb (0.4 kg)
Bone (021)
0
White (020)
555
Linen (222)
0
H2Option® and H2Optimum® Chair Height Elongated Bowl
45 lb (20.6 kg)
White
271
Bone
383
spacer
H2Option® Dual Flush 1.28 gpf/4.8 Lpf and 0.92 gpf/3.5 Lpf 12-Inch Rough Tank
27 lb (12.2 kg)
White
284
Bone
439
spacer
H2Option® Dual Flush 1.28 gpf/4.8 Lpf and 0.92 gpf/3.5 Lpf 12-Inch Rough Lined Tank
27 lb (12.2 kg)
White
317
spacer
H2Option® Dual Flush 12-Inch Rough Toilet Tank Cover
7 lb (3.3 kg)
White
83
Bone
96
Cardiff Slow-Close Elongated Toilet Seat
3 lb (1.5 kg)
White
85
Bone
92
Models marked with * are discontinued, but product may still be available while supplies last.
