Edgemere

Edgemere® Dual Flush 1.28 gpf/4.8Lpf and 1.0gpf/3.8Lpf 12-Inch Rough Tank

The Edgemere Dual Flush 12-Inch Rough-In Tank from American Standard lends classic elegance to the bathroom. Defined by soft angles, this design ensures comfort, style, and superior performance. At the press of a button, the dual flush toilet allows you to activate a partial flush of 1.0 gpf or a full flush of 1.28 gpf, using 21% less water than a standard toilet. Coordinates beautifully with the entire Edgemere Collection.

White 4519A203.020 DISCONTINUED
List Price: $179.00
Cal Green CEC Certified Everclean Water Efficient WaterSense
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Combination bowl and tank, less seat
  • 12" (305 mm) rough-in
  • High efficiency, low consumption, full flush (1.28 gpf/4.8 Lpf), conserving flush (1.0 gpf/3.8 Lpf)
  • Meets EPA WaterSense® criteria
  • PowerWash® rim scrubs bowl with each flush
  • Chrome top-of-tank push button actuator
  • Includes EZ-Install Tools
  • Antimicrobial surface: EverClean® protects against mold, mildew, odor- and stain-causing bacteria
  • 16-1/2" (419 mm) rim height for accessible application
  • 2" (51 mm) fully glazed trapway,9" x 8" (229 x 203 mm) water surface area,Design coordinates with Edgemere® suite
Technical Features
  • Siphon action jet
  • Dual Flush Tank
  • 12" (305mm) rough-in
  • High efficiency, low consumption: Full Flush 1.28gpf/4.8Lpf, Conserving Flush 1.0 gpf/3.8Lpf,
  • Meets EPA WaterSense® Criteria (Pending)
  • EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria
  • Limited Lifetime Warranty
Nominal Dimensions: 17 in x 8-1/2 in x 13-9/16 in (432 mm x 216 mm x 344 mm)
Description
Net Weight
SKU
Color
List Price USD
Edgemere® Dual Flush 1.28 gpf/4.8 Lpf and 1.0 gpf/3.8 Lpf 12 in. Rough Tank
27 lb (12.4 kg)
4519A203.020
White (020)
179
Download Specification Sheet
Brand: American Standard
Cal Green: Yes
Category: Toilets
CEC Certified: Yes
Color / Finish: White
Collections: Edgemere
WaterSense: Yes
Everclean: Yes
Fixture Material: Ceramic
Fixture or Fitting Material: Ceramic
Flush Technology: Dual Flush
Flusing Type: Dual Flush
Gallons Per Flush (min-max): 1.0 - 1.28 GPF
Handle Finish: CHROME
Number of Flush Valves: 1
Height: 13-9/16
Length: 17
Length: 17
Width: 8-1/2
Residential or Commercial: Residential
Subcategory: Floor Standing Toilets
Trip Lever Location: Top
Dual Flush: Yes
Toilet Mount Type: Floor Mount
Toilet Type: Tank Only
Warranty: Limited Lifetime Residential; 10 Year Commercial
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions
