Champion® PRO Two-Piece 1.28 gpf/4.8 Lpf Chair Height Round Front Toilet Less Seat

Features
  • Trade exclusive
  • 12-inch rough-in
  • 1,000 MaP score: Achieves highest rating possible for flush performance
  • Antimicrobial surface: EverClean® protects against mold, mildew, odor- and stain-causing bacteria on the toilet
  • WaterSense® certified: Uses 20 percent less water and performs as well as or better than regular toilets
  • Chair-height comfort: Measures 17” tall, including seat, for ease of use compared to standard height. Slight variation in height may occur based on the height of the seat used.
  • ADA compliant: Meets Americans with Disabilities Act requirements for use and accessibility
  • Metal parts: Robust metal trip lever and metal shank fill valve
  • Finishing touches: Includes color-matched bowl caps and trip lever
  • Durable construction: Made from quality vitreous china for strength and reliability,Less seat: Toilet seat is sold separately
Technical Features
  • Includes tank, bowl, and installation kit (seat not included)
  • Bowl Shape: Round-Front
  • Rim Height: Chair Height measures 17" (with seat) rim height, ADA compliant
  • Rough-In: 12" (305 mm)
  • Configuration: Two-piece exposed trapway design
  • Flush Rate: 1.28 gpf (4.8Lpf) single flush high-efficiency toilet; meets EPA WaterSense® criteria
  • Made with durable metal components including metal trip lever, arm and brass shank
  • Metal trip-lever, chrome
  • Trapway: 2-3/8" (60 mm) fully glazed
  • PowerWash® Rim Design,EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria,EZ-installation kit included, no tools needed,Limited Lifetime Warranty, see warranty page on website for detail
Nominal Dimensions: 28-1/4 in x 19 in x 31 in (718 mm x 483 mm x 787 mm)
Description
Net Weight
SKU
Color
List Price USD
Champion® PRO Two-Piece 1.28 gpf/4.8 Lpf Chair Height Round Front Toilet Less Seat
1 lb (0.4 kg)
0
0
0
Separate Components
Champion® PRO Chair Height Round Front Bowl
57 lb (25.9 kg)
0
spacer
Champion® PRO 1.28 gpf/4.8 Lpf 12-Inch Rough Tank
31 lb (14.1 kg)
0
spacer
Champion® PRO 1.28 gpf/4.8 Lpf 12-Inch Rough Right Hand Trip Lever Tank
32 lb (14.4 kg)
0
spacer
Champion® PRO 1.28 gpf/4.8 Lpf 12-Inch Rough Lined Tank
32 lb (14.4 kg)
0
spacer
Champion® PRO 12-Inch Rough Toilet Tank Cover
8 lb (3.7 kg)
0
spacer
Left-Hand Trip Lever
0 lb (0.2 kg)
0
0
0
0
0
0
0
spacer
Right-Hand Trip Lever
0 lb (0.2 kg)
0
0
Optional Components (Not Included)
Champion® Slow-Close & Easy Lift-Off Round Front Toilet Seat
3 lb (1.4 kg)
0


Models marked with * are discontinued, but product may still be available while supplies last.
ADA Compliant: Yes
Barrier Free: Yes
Front to Back Length: 16-1/2
Bowl Included: Yes
Bowl Shape: Round
Brand: American Standard
Cal Green: Yes
Category: Toilets
CEC Certified: Yes
Chair Height: Chair
Color / Finish: White (020)
Collections: Champion
WaterSense: Yes
Everclean: Yes
Fixture Material: Vitreous China
Fixture or Fitting Material: Vitreous China
Flush Technology: Gravity Fed
Flush Valve Size: 4
Flusing Type: Single Flush
Gallons Per Flush (min-max): 1.28 GPF
MAP Performance Rating: 1000
Number of Batteries Included: Not Applicable (N/A)
Number of Flush Valves: 1
Height: 31
Length: 28-1/4
Length: 28-1/4
Width: 19
Residential or Commercial: Residential
Rough In Size: 12
Rough In Valve Included: Yes
Subcategory: Floor Standing Toilets
Tank Included: Yes
Trip Lever Location: Left Front
Bowl Height With Seat: 18-15/16
Toilet Water Efficiency: Hight Efficiency Toilet
Toilet Mount Type: Floor Mount
Trapway Diameter: 2-3/8
Toilet Type: Two Piece
Warranty: 10 Year Limited Warranty
Water Efficient: Yes
There are no design files currently available for this product
The 3D Models used on the website are for reference only and may not reflect the actual configuration of the product.
