2-Hdl Thermo Rgh Valve W/3Way Div-Shared

The 2-Handle Thermostat from American Standard allows you to shower at a pre-selected water temperature and choose between three separate shower outlets, and an adjustable hot limit safety stop limits the amount of hot water allowed to mix with cold, to reduce the risk of accidental scalding, for a shower that is safer and easier to use than ever before.\nFeatures high quality brass casting for durability and long life. Built-in diverter allows the user to choose between 2 and 3 separate outlets. Wax Thermostatic unit maintains the pre-selected constant water temperature. Back to Back Capable: hot and cold can be reversed.\nSpring-loaded Check valves prevents the cross flow of hot and cold water. Integrated stop valves ensure easy cleaning and servicing. Adjustable hot limit safety stop reduces the risk of accidental scalding. Maximum water temperature limit may be reduced to 104 or 109 degrees Fahrenheit. Compatible with Town Square Shower Trim Kit, Serin Shower Trim Kit, Green Tea Shower Trim Kit, Times Square Shower Trim Kit

Features
  • High quality brass casting for durability and long life
  • Built-in diverter allows the user to choose between 2 and 3 separate outlets
  • Wax Thermostatic unit maintains the pre-selected constant water temperature
  • Back to Back Capable: hot and cold can be reversed
  • Spring-loaded Check valves prevents the cross flow of hot and cold water
  • Integrated stop valves ensure easy cleaning and servicing
  • Adjustable hot limit safety stop reduces the risk of accidental scalding
  • Maximum water temperature limit may be reduced to 104 or 109 degrees Fahrenheit
  • Compatible with: Town Square Shower Trim Kit, Serin Shower Trim Kit, Green Tea Shower Trim Kit, Times Square Shower Trim Kit, Moments Shower Trim Kit, Berwick Shower Trim Kit, Portsmouth Shower Trim Kit, Quentin Shower Trim Kit
Technical Features
  • High quality brass casting for durability and long life
  • Built-in diverter allows the user to choose between 2 and 3 separate outlets
  • Wax Thermostatic unit maintains the pre-selected constant water temperature
  • Back to Back Capable: hot and cold can be reversed
  • Spring-loaded Check valves prevents the cross flow of hot and cold water
  • Integrated stop valves ensure easy cleaning and servicing
  • Adjustable hot limit safety stop reduces the risk of accidental scalding
  • Maximum water temperature limit may be reduced to 104 or 109 degrees Fahrenheit
  • Compatible with: Town Square Shower Trim Kit, Serin Shower Trim Kit, Green Tea Shower Trim Kit, Times Square Shower Trim Kit, Moments Shower Trim Kit, Berwick Shower Trim Kit, Portsmouth Shower Trim Kit, Quentin Shower Trim Kit
Description
Net Weight
SKU
Color
List Price USD
2-Hdl Thermo Rgh Valve W/3Way Div-Shared
6 lb (2.8 kg)
No Finish (007)
374
Substitutions
Flash® 2-Way Shared Diverter Cartridge
0 lb (0.1 kg)
No Finish
79


Models marked with * are discontinued, but product may still be available while supplies last.
Brand: American Standard
Category: Rough-ins Concealed Bodies
Color / Finish: No Finish
Collections: Roughs/Valves
Fitting Connection Size Input: 12.70
Fitting Material: Brass
Fixture or Fitting Material: Brass
Input Connection Type: NPT (National Pipe Tapered Threads)
Number of Input Valves: 2
Number of Output Valves: 3
Output Connection Type: NPT (National Pipe Tapered Threads)
Height: 9.25
Length: 3-5/8
Residential or Commercial: Residential
Subcategory: Thermostat Valve Rough in
