Rapid SL

Rapid SL Slim 2” x 4” In-Wall Carrier for Toilet

The GROHE Rapid SL Slim In-Wall Carrier represents the next level of innovation from the leader in the engineering and development of in-wall carriers. Designed to fit in thinner walls, with features that ensure easy installation, the Rapid SL Slim Carrier is whisper-quiet, water-conserving, easy to connect without tools, and essential in today’s home.

No Finish 39688000 DISCONTINUED
List Price: $805.00
ADA Compliant Enjoy More Rewards Water Efficient
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • German design and engineering
  • Optional Flow Manager to accommodate rimless bowls, sold separately
  • GROHE Whisper delivers whisper-quiet acoustics for a more serene environment
  • GROHE EcoJoy conserves water without sacrificing performance
  • GROHE ToolFree installation ensures no tools are needed to connect the main water supply, flexible hose and inspection shaft
  • GROHE EasyConnect features a pneumatic hose that connects the flush valve to the flush plate to accommodate all tile thicknesses
  • GROHE QuickFix ensures flexibility and ease of installation, significantly cutting installation time
  • GROHE VarioPort allows the supply hose to be attached at four points: front, rear, left or right
  • GROHE Safety, Rapid SL certifies load bearing capacity and stability of the carrier has been confirmed at 880 lbs. (400 kg)
  • WaterSense compliant when paired with listed WaterSense high efficiency compatible 0.8-1.28gpf (3-4.8lpf) wall hung toilet bowls,For use with small flush plates 5 1?8” x 6 ¾” (130 x172 mm), please order shaft 40 911 000 (sold separately)
Technical Features
  • Slim tank fits standard 2" x 4" stud walls
  • Dual flush – 0.8gpf and 1.6gpf (3Lpf and 6Lpf)
  • Low noise operation – meets strict European noise (DIN) standards
  • No tools required for the installation of the inspection shaft including protection during construction phase, for vertical use
  • Self-supporting, pre-assembled powder coated steel frame with quick and lockable adjustments
  • ADA Compliant, bowl rim height adjustment from 15" to 19"
  • Pneumatic discharge valve offering 3 modes of operation: dual flush, start/stop or single flush
  • Tank insulated to prevent condensation
  • 2 fixing bolts included, 7"-9" (180-230mm) mounting screw distance
  • 1/2” water supply connection from top, integrated angle valve,Small size (37 535) series actuation plate required and sold separately,TÜV approved for load capacity,44" (1.13m) installation height,CALGreen compliant,WaterSense compliant when paired with listed WaterSense high efficiency compatible 0.8-1.28gpf (3-4.8Lpf) wall hung toilet bowls
Description
Net Weight
SKU
Color
List Price USD
Rapid SL Slim 2” x 4” In-Wall Carrier for Toilet
34 lb (15.4 kg)
39688000
No Finish (00G)
805
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: GROHE
Category: Flush Valves and Sanitary Items
Color / Finish: No Finish
Collections: Rapid SL
Gallons Per Flush (min-max): 0.8 - 1.6 GPF
Residential or Commercial: Residential
Subcategory: Wall Carriers Flush Valves
Warranty: 10 Year Limited Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions
Download All Design Files
2D CAD Files
.dxf icon 2D CAD File
.dxf icon 2D CAD File
3D CAD Files
.dxf icon 3D CAD File
REVIT Files
.rfa icon REVIT File
There are no videos currently available for this product
3D Objects are not currently available for this product
