Allbrook 0.5 gpf Siphon Jet Top Spud Urinal with Manual Flush Valve System

This high-efficiency urinal uses just 0.5 gallons per flush, which is 50% less than a standard urinal. Features include a flushing rim and siphon jet flush action. Manual flush valve delivers superior flush accuracy and repeat ability, and a self-cleaning brass piston prevents clogging and reduces maintenance.

Features
  • Vitreous china
  • High Efficiency. Operates in the range of 0.5 gpf to 1.0 gpf (1.9 Lpf to 3.8 Lpf)
  • Flushing rim
  • Siphon jet flush action
  • 3/4" inlet spud
  • Outlet connection threaded 2" inside (NPTF)
  • Meets ANSI flush requirements at 0.5 to 1.0 gpf
  • Wall hanger
  • Fixture only
Technical Features
  • Vitreous china
  • High Efficiency. Operates in the range of 0.5 gpf to 1.0 gpf (1.9 Lpf to 3.8 Lpf)
  • Flushing rim
  • Siphon jet flush action
  • 3/4" inlet spud
  • Outlet connection threaded 2" inside (NPTF)
  • Meets ANSI flush requirements at 0.5 to 1.0 gpf
  • Wall hanger
  • Fixture only
Description
Net Weight
SKU
Color
List Price USD
Allbrook 0.5 gpf Siphon Jet Top Spud Urinal with Manual Flush Valve System
38 lb (17.2 kg)
White (020)
0
Separate Components
Ultima Manual Urinal Flush Valve, Piston-Type, 0.5 gpf/1.9 Lpf
6 lb (2.6 kg)
Chrome
351
spacer
Allbrook® 0.5 – 1.0 gpf (1.9 – 3.8 Lpf) Top Spud Siphon Jet Urinal
28 lb (12.9 kg)
White
245
Substitutions
Allbrook® 0.5 – 1.0 gpf (1.9 – 3.8 Lpf) Top Spud Siphon Jet Urinal
28 lb (12.9 kg)
White
245


Models marked with * are discontinued, but product may still be available while supplies last.
Brand: American Standard
Category: Flush Valves and Sanitary Items
Color / Finish: White
Collections: Allbrook
WaterSense: Yes
Fixture Material: Vitreous China
Fixture or Fitting Material: Vitreous China
Gallons Per Flush (min-max): 0.5 GPF
Residential or Commercial: Commercial
Subcategory: Manual Flush Valve and Sanitary Items
Warranty: Limited Lifetime Warranty
Water Efficient: Yes
