Features
- Removal:
- Turn off the water supply and flush the toilet to empty the tank
- Remove the tank cover
- Open the cover on the battery compartment and disconnect the battery cable from the battery terminal
- Pull the locking collar off of the hose assembly using a twisting motion then remove the hose from the end of the actuator
- Make sure the O-ring is reinstalled on the barb at the end of the actuator
- Remove the refill tube clip from the flush valve body
- Grasp the tabs on each side of the flush valve body and pull in an upward motion
- Remove the float with seal from the valve
Technical Features
- Removal:
- Turn off the water supply and flush the toilet to empty the tank
- Remove the tank cover
- Open the cover on the battery compartment and disconnect the battery cable from the battery terminal
- Pull the locking collar off of the hose assembly using a twisting motion then remove the hose from the end of the actuator
- Make sure the O-ring is reinstalled on the barb at the end of the actuator
- Remove the refill tube clip from the flush valve body
- Grasp the tabs on each side of the flush valve body and pull in an upward motion
- Remove the float with seal from the valve
Nominal Dimensions: 2.7 in x 3.8 in x 5.3 in (69 mm x 97 mm x 135 mm)
There are no additional components to display for this product
Brand:
American Standard
Category:
Fixtures and Vanities Spare Parts
Color / Finish:
No Finish
Collections:
Repair Parts
Height:
5.3
Length:
2.7
Width:
3.8
Residential or Commercial:
Repair Parts
Subcategory:
Flush Valves & Flappers
