Yorkville

Yorkville® Two-Piece Pressure Assist 1.6 gpf/6.0 Lpf Chair Height Back Outlet Elongated EverClean® Toilet

The American Standard Yorkville® Two-Piece Commercial Toilet is robustly engineered for the demanding use of high-traffic commercial environments such as hospitals, offices, or municipal facilities. This durable vitreous china fixture combines ADA-compliant chair-height seating for accessible bathrooms and user comfort, with a powerful pressure-assisted flushing system to ensure forceful, non-clog performance. Its back-outlet design and robust construction make it an ideal commercial toilet solution for renovation or new construction projects. The Yorkville® is a low-consumption model that meets standard 1.6 gpf commercial water usage requirements, and features the EverClean® antimicrobial surface for superior long-term hygiene and easy maintenance. Toilet seat is sold separately.

White 2878016.020 DISCONTINUED
List Price: $970.00
ADA Compliant Everclean USMCA Compliant
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Commercial-grade pressure-assist: Features pressure-assisted siphon jet action that ensures a powerful, reliable flush and non-clog performance, making it ideal for high-use commercial applications
  • ADA-compliant comfort height: The 16 ½ inch chair-height bowl makes sitting and standing easier for all users, including seniors, adults, and those with mobility issues
  • Superior hygiene: The EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria on the toilet surface
  • Low-consumption water use: A low-consumption 1.6 gpf / 6.0 Lpf rating meets standard commercial water usage requirements
  • Clog resistance: Equipped with a fully-glazed 2 1/8 inch trapway to resist clogs and maintain optimal flushing performance
  • Easy maintenance: A close-coupled tank and sanitary bar on the bowl create a clean, modern profile that is easy for maintenance staff to wipe down
  • Fast installation: Uses the proprietary Speed Connect® tank/bowl coupling system for fast and secure installation, reducing labor time
  • Durable hardware: Includes a metal chrome-plated trip lever and 4 color-matched bolt caps
  • Working pressure: Recommended operating pressure range of 25 psi - 80 psi
  • Note: Toilet seat is sold separately
Technical Features
  • Floor-mounted, back-outlet toilet bowl and tank less seat
  • Pressure-assisted siphon jet action
  • Low consumption (1.6 gpf/6.0 Lpf)
  • EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria
  • 16-1/2" (419 mm) Chair Height for accessible applications
  • 2-1/8" (54 mm) fully-glazed trapway
  • Condensation channel
  • 10" x 12" water surface area
  • Chrome-plated metal trip lever
  • 4 color-matched bolt caps included
Nominal Dimensions: 29-3/4 in x 20-1/2 in x 30-3/4 in (756 mm x 521 mm x 781 mm)
Description
Net Weight
SKU
Color
List Price USD
Yorkville® Two-Piece Pressure Assist 1.6 gpf/6.0 Lpf Chair Height Back Outlet Elongated EverClean® Toilet
1 lb (0.4 kg)
2878016.020
White (020)
970
2878016.021 *
Bone (021)
0
2878016.222 *
Linen (222)
0
Separate Components
Yorkville® Pressure Assist Chair Height Back Outlet Elongated EverClean® Bowl
57 lb (25.9 kg)
3703001.020
White
576
spacer
Pressure Assist 1.6 gpf/6.0 Lpf Left-Hand Trip Lever EverClean® Tank
42 lb (19.2 kg)
4142016.020
White
394
spacer
7381886-201.0020A-PRESSURE POD LH TRIP LEVER
0 lb (0.0 kg)
7381886-201.0020A
Chrome
108
spacer
7381886-202.0020A-PRESSURE POD RH TRIP LEVER
0 lb (0.0 kg)
7381886-202.0020A
Chrome
108
Optional Components (Not Included)
Pressure Assist 1.6 gpf/6.0 Lpf Left-Hand Trip Lever EverClean® Tank With Tank Cover Locking Device
42 lb (19.2 kg)
4142600.020
White
591
spacer
Pressure Assist 1.6 gpf/6.0 Lpf Right-Hand Trip Lever EverClean® Tank
42 lb (19.2 kg)
4142800.020
White
401
spacer
Pressure Assist 1.6 gpf/6.0 Lpf Right-Hand Trip Lever EverClean® Tank With Tank Cover Locking Device
42 lb (19.2 kg)
4142900.020
White
598
spacer
Tank cover for locking device
7 lb (3.3 kg)
735133-401.020
White
92


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Front to Back Length: 16-1/2
Bowl Shape: Elongated
Brand: American Standard
Category: Commercial Toilet
Chair Height: Standard
Color / Finish: White
Collections: Yorkville
Everclean: Yes
Fixture Material: Vitreous China
Flush Technology: Pressure Assisted
Flush Valve Size: 2
Flusing Type: Single Flush
Gallons Per Flush (min-max): 1.6 GPF
Height: 30-3/4
Length: 29-3/4
Width: 20-1/2
Residential or Commercial: Commercial
Rough In Size: 12
Subcategory: Floor Standing Commercial Toilet
Toilet Mount Type: Floor Mount
Toilet Type: Floor_Standing_Two_Piece_Toilet
USMCA Compliant: Yes
Warranty: 1 Year Limited Warranty
Download All Supporting Documents

Specification Sheet

Installation Instructions
