Selectronic

Serin® Touchless Wall-Mount Trim, Base Model, 1.5 gpm/5.7 Lpm

The Serin wall-mount faucet for commercial bathrooms from American Standard combines style, innovation, and functionality. Its durable metal body is vandal-resistant for long-lasting beauty, and a space-saving wall-mount design looks and works great. Power kits sold separately. Sensor in Spout Tip: Clean, streamlined style. Hidden sensor reduces vandalism. Hygienic, touch-free operation. Adjustable Spout Reach: Easily adjustable from 6" - 9" (from the wall to the outlet). Self-Cleaning Solenoid Reduces Maintenance: Integral wiper spring prevents clogging and run-on. Easy to Service Integrated Strainer: Patented in-line strainer protects the solenoid from debris. Strainer is enclosed in removable debris cup for easy service.

Chrome T06B302.002 DISCONTINUED
List Price: $616.00
ADA Compliant Environmental Product Declaration Water Efficient
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • POWER KIT MUST BE PURCHASED SEPARATELY
  • R350 rough valve must be purchased separately
  • Touchless operation limits the spread of germs
  • Sensor in spout tip for streamlined style and reduced vandalism
  • Self-adjusting sensor automatically sets range for optimum performance
  • Adjustable Spout Reach: Easily adjustable from 6-inch (152 mm) – 9-inch (229 mm)
  • Vandal-resistant brass spout
  • Single inlet for cold or tempered water
  • Safety Timer: Automatically turns water off after 55 seconds
  • Vandal-resistant 1.5 gpm/5.7 Lpm pressure-compensating laminar flow outlet
Technical Features
  • POWER KIT MUST BE PURCHASED SEPARATELY
  • R350 rough valve must be purchased separately
  • Touchless operation limits the spread of germs
  • Sensor in spout tip for streamlined style and reduced vandalism
  • Self-adjusting sensor automatically sets range for optimum performance
  • Adjustable Spout Reach: Easily adjustable from 6" (152 mm) – 9" (229 mm)
  • Vandal-resistant brass spout
  • Safety Timer: Automatically turns water off after 55 seconds
  • Single inlet for cold or tempered water
Nominal Dimensions: 8.8 in x 2.7 in x 3.5 in (224 mm x 69 mm x 89 mm)
Description
Net Weight
SKU
Color
List Price USD
Serin® Touchless Wall-Mount Trim, Base Model, 1.5 gpm/5.7 Lpm
7 lb (3.0 kg)
T06B302.002 *
Chrome (002)
616
T06B302.295 *
Brushed Nickel (295)
819


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: American Standard
Category: Commercial Fittings
Color / Finish: Chrome
Collections: Selectronic
Drain Material: Metal
Fitting Connection Size Input: 3/8
Fitting Material: Brass
Mount Type: Deck Mount
Fitting Number of Holes: 1
Spout Height: 3
Spout Type: Standard
Touchless: Touchless
Fixture or Fitting Material: Brass
Gallons Per Minute (min-max): 1.5 GPM
Hardware Included: Yes
Height: 3.5
Length: 8.8
Width: 2.7
Residential or Commercial: Commercial
Subcategory: Sensor Commercial Fittings
Warranty: 5 Year Limited Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Environmental Product Declaration
