Find Your Salesperson

Selectronic

NextGen Selectronic® Touchless Faucet, Battery-Powered, 0.35 gpm/1.3 Lpm

The NextGen Selectronic® Touchless Faucet from American Standard has a sleek, clean design that brings elevated style to the bathroom. Equipped with an advanced sensor, the NextGen faucet self-calibrates to the environment and lighting conditions, greatly reducing the need to make manual adjustments. Integrated engineering, with all electronics in the spout, makes installation and maintenance hassle-free by eliminating the below deck control box, resulting in a clean, clutter-free under-deck space. Enhanced remote control, sold separately, features an intuitive display and convenient monitoring of multiple faucets.

Chrome 7766103.002 DISCONTINUED
List Price: $512.00
ADA Compliant Cal Green CEC Certified Water Efficient
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Self-calibrating sensor: Advanced sensor is self-calibrating based on environment and lighting, reducing the maintenance time needed for manual adjustments
  • Easy above-deck installation: All electronics are located in the spout for quick installation, hassle-free maintenance, and elimination of the below-deck box creating more space under the deck
  • Uses 20% less power: Using less power extends battery life, reducing costs, downtime and the maintenance time needed for replacement
  • Touchless for better hygiene: Helps to reduce the spread of germs
  • Single inlet: For cold or tempered water
  • Auto purge convenience: Periodically purges stagnant water to promote a cleaner, healthier environment
  • Auto shut-off saves water: Automatically turns water off after 55 seconds
  • Battery included: 6-year CR-P2 lithium battery installed in the faucet
  • Vandal resistant: Designed to prevent damage, tampering and theft
  • Improved lead-free compliance: Meets code requirements to install with confidence,Optional remote control: Easily customize, maintain, and troubleshoot Selectronic® faucets and flush valves. Model 605XRCW, sold separately,Optional deck plate available: Choose 4 in. (102 mm) or 8 in. (203 mm), sold separately
Technical Features
  • 6-year CR-P2 lithium battery installed in faucet
  • Touchless operation limits the spread of germs
  • Clean, integrated design. No control box below deck
  • Less mixing
  • Easy installation and maintenance: Faucet installs from the top. All serviceable parts are easily accessible
  • Auto Purge: Periodically purges stagnant water
  • Safety Timer: Automatically turns water off after 55 seconds
  • Adjustable Range: Detection zone can be adjusted manually or with optional remote control
  • Single inlet for cold or tempered water
  • Optional deck plates and remote control available (sold separately)
Description
Net Weight
SKU
Color
List Price USD
NextGen Selectronic® Touchless Faucet, Battery-Powered, 0.35 gpm/1.3 Lpm
2 lb (1.0 kg)
7766103.002
Chrome (002)
512
Optional Components (Not Included)
NextGen 4-Inch Deck Plate
1 lb (0.2 kg)
706P400.002
Chrome
58
706P400.243
Matte Black
83
706P400.295
Brushed Nickel
77
706P400.GN0
Brushed Cool Sunrise
90
spacer
NextGen 8-Inch Deck Plate
1 lb (0.3 kg)
706P800.002
Chrome
95
706P800.243
Matte Black
137
706P800.295
Brushed Nickel
113
706P800.GN0
Brushed Cool Sunrise
148
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: American Standard
Cal Green: Yes
Category: Commercial Fittings
CEC Certified: Yes
Color / Finish: Chrome
Department of Energy Certified: Yes
Collections: Selectronic
Gallons Per Minute (min-max): 0.35 GPM
Residential or Commercial: Commercial
Subcategory: Sensor Commercial Fittings
Warranty: 5 Year Limited Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
3D Objects are not currently available for this product
