Selectronic

NextGen Selectronic® Touchless Faucet, Base Model With Above-Deck Mixing, 0.5 gpm/1.9 Lpm

The NextGen® Selectronic® Touchless Faucet from American Standard has a sleek, clean design that brings elevated style to the bathroom. Equipped with an advanced sensor, the NextGen faucet self-calibrates to the environment and lighting conditions, greatly reducing the need to make manual adjustments. Removable above-deck mixing handle to set water temperature then remove handle to prevent tampering. Integrated engineering, with all electronics in the spout, makes installation and maintenance hassle-free by eliminating the below deck control box, resulting in a clean, clutter-free under-deck space. Enhanced remote control, sold separately, features an intuitive display and convenient monitoring of multiple faucets.

Brushed Nickel 706B205.295 DISCONTINUED
List Price: $615.00
ADA Compliant Cal Green CEC Certified Water Efficient
Items REQUIRED for Install
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • POWER KIT MUST BE PURCHASED SEPARATELY
  • Self-calibrating sensor: Advanced sensor is self-calibrating based on environment and lighting, reducing the maintenance time needed for manual adjustments
  • Above-deck handle: Set temperature and remove handle to prevent tampering; cover plug is included
  • Dual inlets: For hot and cold water
  • Easy above-deck installation: All electronics are located in the spout for quick installation, hassle-free maintenance, and elimination of the below-deck box creating more space under the deck
  • Uses 20% less power: Using less power extends battery life, reducing costs, downtime and the maintenance time needed for replacement
  • Touchless for better hygiene: Helps to reduce the spread of germs
  • Auto purge convenience: Periodically purges stagnant water to promote a cleaner, healthier environment
  • Auto shut-off saves water: Automatically turns water off after 55 seconds
  • Vandal resistant: Designed to prevent damage, tampering and theft,Improved lead-free compliance: Meets code requirements to install with confidence,Optional remote control: Easily customize, maintain, and troubleshoot Selectronic® faucets and flush valves. Model 605XRCW, sold separately,Optional deck plate available: Choose 4 in. (102 mm) or 8 in. (203 mm), sold separately
Technical Features
  • POWER KIT MUST BE PURCHASED SEPARATELY
  • Touchless operation limits the spread of germs
  • Above-deck mixing with removable handle
  • Clean, integrated design. No control box below deck
  • Easy installation and maintenance: Faucet installs from the top. All serviceable parts are easily accessible
  • Auto Purge: Periodically purges stagnant water
  • Safety Timer: Automatically turns water off after 55 seconds
  • Adjustable Range: Detection zone can be adjusted manually or with optional remote control
  • Dual inlets for hot and cold water
  • Optional deck plates and remote control available (sold separately)
Description
Net Weight
SKU
Color
List Price USD
NextGen Selectronic® Touchless Faucet, Base Model With Above-Deck Mixing, 0.5 gpm/1.9 Lpm
2 lb (1.0 kg)
706B205.295
Brushed Nickel (295)
615
706B205.002
Chrome (002)
492
706B205.243
Matte Black (243)
664
706B205.GN0
Brushed Cool Sunrise (GN0)
713
Required Components (Not Included)
Selectronic® PWRX Power Kit
0 lb (0.2 kg)
PK00.WRK
No Finish
172
spacer
Selectronic® Hard Wired AC Power Kit
1 lb (0.3 kg)
PK01.HAC
No Finish
140
spacer
Selectronic® Multi-AC Power Kit
0 lb (0.1 kg)
PK01.MAC
No Finish
83
spacer
Selectronic® Plug-In AC Power Kit
1 lb (0.4 kg)
PK01.PAC
No Finish
109
Optional Components (Not Included)
NextGen 4-Inch Deck Plate
1 lb (0.2 kg)
706P400.002
Chrome
58
706P400.243
Matte Black
83
706P400.295
Brushed Nickel
77
706P400.GN0
Brushed Cool Sunrise
90
spacer
NextGen 8-Inch Deck Plate
1 lb (0.3 kg)
706P800.002
Chrome
95
706P800.243
Matte Black
137
706P800.295
Brushed Nickel
113
706P800.GN0
Brushed Cool Sunrise
148
spacer
Selectronic® Battery Back-Up Kit
0 lb (0.1 kg)
PK00.BBU
No Finish
110
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: American Standard
Cal Green: Yes
Category: Commercial Fittings
CEC Certified: Yes
Color / Finish: Brushed Nickel
Department of Energy Certified: Yes
Collections: Selectronic
Gallons Per Minute (min-max): 0.5 GPM
Residential or Commercial: Commercial
Subcategory: Sensor Commercial Fittings
Warranty: 5 Year Limited Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions
