Features
- 3/8" Gooseneck spout
- Spray outlet 7-11/16" (195 mm) above slab
- Height 12" (302 mm), Reach 5-9/16" (142 mm)
- Coupling nut for 1/4" tailpiece
- Max installation thickness 1-9/16" (40mm)
- Brass Construction: Durable - excellent in high use applications.
- Polished Chrome Finish: Excellent in commercial applications.
- 1.5 gpm/5.7 Lpm pressure-compensating aerator
Technical Features
- 3/8" Gooseneck spout
- Spray outlet 7-11/16" (195 mm) above slab
- Height 12" (302 mm), Reach 5-9/16" (142 mm)
- Coupling nut for 1/4" tailpiece
- Max installation thickness 1-9/16" (40mm)
- Brass Construction: Durable - excellent in high use applications.
- Polished Chrome Finish: Excellent in commercial applications.
- 1.5 gpm/5.7 Lpm pressure-compensating aerator
Nominal Dimensions: 6.8 in x 1.7 in x 11.9 in (173 mm x 43 mm x 302 mm)
