Monterrey

Monterrey® 8-Inch Widespread 8-inch Reach Gooseneck Faucet with Wrist Blade Handles 0.5 gpm/1.9 Lpm

Every American Standard Commercial Faucet is designed to work flawlessly and dependably year after year, saving time, money and maintenance headaches.

Chrome 6540177.002 DISCONTINUED   Substitution Available (6540178.002)
List Price: $329.00
ADA Compliant Cal Green CEC Certified Water Efficient
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Field-convertible rigid/swivel gooseneck spout with 8" (203 mm) reach
  • Cast brass valve bodies with 8" (203 mm) rigid copper connections
  • 1/2" (13 mm) male threaded inlet shanks with brass coupling nuts
  • Washerless ceramic disc valves assure drip-free performance
  • Vandal-resistant wrist blade handles with red and blue indicies
  • 0.5 gpm/1.9 Lpm pressure-compensating VR multi-laminar spray
  • Lead-Free
  • ADA Compliant
  • 5-Year Limited Warranty for commercial installations
Technical Features
  • Field-convertible rigid/swivel gooseneck spout with 8" (203 mm) reach
  • Cast brass valve bodies with 8" (203 mm) rigid copper connections
  • 1/2" (13 mm) male threaded inlet shanks with brass coupling nuts
  • Washerless ceramic disc valves assure drip-free performance
  • Vandal-resistant wrist blade handles with red and blue indicators
  • 0.5 gpm/1.9 Lpm pressure-compensating VR multi-laminar spray
Nominal Dimensions: 9-1/20 in x 15-11/16 in x 10-1/2 in (230 mm x 398 mm x 267 mm)
Description
Net Weight
SKU
Color
List Price USD
Monterrey® 8-Inch Widespread 8-inch Reach Gooseneck Faucet with Wrist Blade Handles 0.5 gpm/1.9 Lpm
5 lb (2.1 kg)
6540177.002
Chrome (002)
329
Substitutions
Monterrey® 8-Inch Widespread 8-inch Reach Gooseneck Faucet With Wrist Blade Handles 1.5 gpm/5.7 Lpm
5 lb (2.1 kg)
6540178.002
Chrome
348
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: American Standard
Cal Green: Yes
Category: Commercial Fittings
CEC Certified: Yes
Color / Finish: Chrome
Collections: Monterrey
Fitting Material: Brass
Number of Handles: 2
Fitting Number of Holes: 3
Fixture or Fitting Material: Brass
Gallons Per Minute (min-max): 0.5 GPM
Height: 10-1/2
Length: 9-1/20
Width: 15-11/16
Residential or Commercial: Commercial
Subcategory: Mechanical Commercial Fittings
Warranty: 5 Year Limited Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions

Replacement Parts
