Commercial Shower Systems

Commercial Shower System Trim Kit 2.5 gpm/9.5 Lpm With 36-Inch Slide Bar, Hand Shower and Showerhead

TU662223.002 DISCONTINUED   Substitution Available (TU662224.002)
List Price: $0.00
Items REQUIRED for Install
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • For Flash® shower rough-in valves with choice of connections (sold separately)
  • 2-way rough diverter valve (R422 - sold separately)
  • Includes 3-function hand shower with pause feature
  • Pause Feature: Non-positive shut-off button on handle reduces flow to a trickle to meet ADA requirement
  • 2-way diverter valve trim kit
  • Fixed showerhead with arm and flange
  • 36" slide bar
  • Metal wall escutcheon with metal lever handle. Red/blue indicator ring
  • 2.5 gpf/9.5 Lpm maximum flow rate
Technical Features
  • For Flash® shower rough-in valves with choice of connections (sold separately)
  • 2-way rough diverter valve (R422 - sold separately)
  • Includes 3-function hand shower with pause feature
  • Pause Feature: Non-positive shut-off button on handle reduces flow to a trickle to meet ADA requirement
  • 2-way diverter valve trim kit
  • Fixed showerhead with arm and flange
  • 36" slide bar
  • Metal wall escutcheon with metal lever handle. Red/blue indicator ring
  • 2.5 gpf/9.5 Lpm maximum flow rate
Description
Net Weight
SKU
Color
List Price USD
Commercial Shower System Trim Kit 2.5 gpm/9.5 Lpm With 36-Inch Slide Bar, Hand Shower and Showerhead
9 lb (4.2 kg)
TU662223.002
0
Required Components (Not Included)
2-Way In-Wall Diverter Rough-In Valve With 2 Discrete Functions
2 lb (0.7 kg)
R422
0
Separate Components
Standard 36-Inch Shower Slide Bar
2 lb (0.8 kg)
1660236.002
0
spacer
1/2-Inch NPT In-Line Vacuum Breaker
0 lb (0.1 kg)
1660400.002
0
spacer
2.5 gpm/9.5 Lpf 3-Function Hand Shower With Pause Feature
0 lb (0.2 kg)
1660767.002
0
spacer
Metal Shower Hose
1 lb (0.3 kg)
8888035.002
0
spacer
Wall Supply
1 lb (0.3 kg)
8888037.002
0
spacer
Easy Clean 2.5 gpm/9.5 L/min Fixed Showerhead
1 lb (0.4 kg)
8888075.002 *
0
spacer
Heritage Metal Lever Handle Trim Kit for Diverter Valves
2 lb (0.8 kg)
T342430.002
0
spacer
Reliant 3® Valve Only Trim Kit With Double Ceramic Pressure Balance Cartridge With Lever Handle
2 lb (0.7 kg)
TU385500WD.002 *
0
Substitutions
Commercial Shower System Trim Kit 2.5 gpm/9.5 Lpm with 36-Inch Slide Bar, Hand Shower, Showerhead and Tub Spout
9 lb (4.2 kg)
TU662224.002 *
0


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
Brand: American Standard
Category: Commercial Fittings
Color / Finish: Chrome (002)
Collections: Commercial Shower Systems
Gallons Per Minute (min-max): 2.5 GPM
Height: 35.4
Length: 0
Width: 7.4
Residential or Commercial: Commercial
Subcategory: Mechanical Commercial Fittings
