Features
- Contemporary design
- Faucet ledge with generous shelf area
- Rear overflow
- Faucet holes on 8" (203 mm) centers
- Soap/accessory ledge
- Optional integral mounted towel bar
- Supplied with mounting kit
- 24-1/4" x 20" (616 x 508 mm)
- 34" (864 mm) height
Technical Features
- Contemporary design
- Faucet ledge with generous shelf area
- Rear overflow
- Soap/accessory ledge
- Available integral mounted towel bar (order separately)
- Supplied with mounting kit
- Made of vitreous china
Nominal Dimensions: 24-1/4 in x 20 in x 34 in (616 mm x 508 mm x 864 mm)
Ravenna® 8-Inch Widespread Pedestal Sink Top and Leg Combination
1 lb (0.4 kg)
White (020)
392
Black (178)
431
Ravenna® Pedestal Leg
1 lb (0.4 kg)
White
124
spacer
Ravenna® 8-Inch Widespread Pedestal Sink Top
41 lb (18.8 kg)
White
268
Ravenna® Semi-Pedestal Sink Integral Towel Bar
2 lb (0.8 kg)
Chrome
102
Brushed Nickel
125
Ravenna® 8-Inch Widespread Pedestal Sink Top and Leg Combination
1 lb (0.4 kg)
White (020)
392
Black (178)
431
Ravenna® Pedestal Leg
1 lb (0.4 kg)
White
124
spacer
Ravenna® 8-Inch Widespread Pedestal Sink Top
41 lb (18.8 kg)
White
268
Ravenna® Semi-Pedestal Sink Integral Towel Bar
2 lb (0.8 kg)
Chrome
102
Brushed Nickel
125
Models marked with * are discontinued, but product may still be available while supplies last.
