Colony®

Colony® 33 x 22-Inch Stainless Steel 3-Hole Topmount Double-Bowl Kitchen Sink With Colony® PRO Single Control Faucet System

Stainless Steel 20DB.8332283C.075 DISCONTINUED
List Price: $501.00
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Durable 20-gauge stainless steel
  • Convenient top mount installation
  • 33 x 22 x 8-inch double bowl sink
  • Includes Colony Pro stainless steel single control faucet (7074000.075) and (2) 9028000.075 waste fittings
  • Installation hardware, cutout template and instructions included
  • 36" (914 mm) cabinet required
  • Equipped with SoundSecure rubber sound pads on the bottom of your sink to reduce excess sound and vibration
  • Features StoneLock multi-layer spray insulation to help with sound absorption and to minimize condensation on the underside of your sink
  • Each bowl size: 14 x 16 x 8-inch
Technical Features
  • 20 gauge stainless steel
  • Stamped double bowl
  • 8" (203 mm) deep bowls
  • Top mount 3-hole sink
  • SoundSecure sound pads
  • StoneLock undercoating
  • Two waste fittings & sink clips included
  • 36" (914 mm) cabinet required
  • Sink clips included
  • 36" (914 mm) cabinet required
Nominal Dimensions: 21-15/16 in x 32-15/16 in x 8 in (557 mm x 837 mm x 203 mm)
Description
Net Weight
SKU
Color
List Price USD
Colony® 33 x 22-Inch Stainless Steel 3-Hole Topmount Double-Bowl Kitchen Sink With Colony® PRO Single Control Faucet System
19 lb (8.5 kg)
20DB.8332283C.075 *
Stainless Steel (075)
501
Separate Components
Colony® 33 x 22-Inch Stainless Steel 3-Hole Topmount Double-Bowl Kitchen Sink
16 lb (7.1 kg)
20DB.8332283S.075
Stainless Steel
485
spacer
Colony® PRO Single-Handle Kitchen Faucet 1.5 gpm/5.7 L/min
3 lb (1.5 kg)
7074000.075
Stainless Steel
234
spacer
Top Mount Sink Clips
0 lb (0.2 kg)
791637-100.0070A
No Finish
16
spacer
Waste Fitting
1 lb (0.3 kg)
9028000.075
Stainless Steel
39


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
Mount Type: Drop-In
Below Counter Depth: 8
Front To Back Length: 14
Side to Side Width: 16
Top to Bottom Depth: 8
Brand: American Standard
Category: Kitchen Sinks
Color / Finish: Stainless Steel
Collections: Colony®
Mount Locatiion: Drop-In
Height: 8
Height: 8
Length: 21-15/16
Width: 32-15/16
Residential or Commercial: Residential
Below Counter Depth: 8
Bowl Split Ratio: 50/50
Sink Cutout Dimensions: 32.36 in x 21.38 in x 8 in
Sink Finish: Satin
Sink Width (front to back): 22
Sink Length (left to right): 33
Sink Material: Stainless Steel
Number of Basins: 2
Sink Shape: Rectangle
Sink Depth: 8
Subcategory: Double Bowl Kitchen Sinks
Warranty: Limited Lifetime Warranty
Download All Supporting Documents

Specification Sheet

Installation Instructions
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
2D CAD Files
.dxf icon 2D CAD File
REVIT Files
.rfa icon REVIT File
There are no videos currently available for this product
3D Objects are not currently available for this product
