Features
- Swivel spout
- Spout height 6" (152mm)
- Pull-out spray with adjustable spray pattern
- No visible button or toggle-simply pull down to switch from stream to spray
- Metal lever handle
- Can be mounted with or without supplied escutcheon
- 21" (508mm) braided flexible supply hoses with 3/8" compression connectors
Technical Features
- Metal lever handle
- Can be mounted with or without supplied escutcheon
- 20" (508 mm) braided flexible supply hoses with 3/8" (10 mm) compression connectors
- Swivel spout
- Spout height: 7-3/16" (183 mm)
- Spout clearance: 3-13/16" (97 mm)
- Pull-out spray with adjustable spray pattern
- No visible button or toggles — simply pull down to switch from stream to spray
- Washerless ceramic disc valve cartridge (47 mm)
Nominal Dimensions: 11.4 in x 10 in x 8.7 in (290 mm x 254 mm x 221 mm)
Colony® Soft Single-Handle Pull-Out Dual Spray Kitchen Faucet 2.2 gpm/8.3 L/min
5 lb (2.4 kg)
Chrome (002)
286
Stainless Steel (075)
370
0
Colony® PRO Single-Handle Pull-Out Dual Spray Kitchen Faucet 1.5 gpm/5.7 L/min
7 lb (3.4 kg)
Chrome
310
Colony® Soft Single-Handle Pull-Out Dual Spray Kitchen Faucet 2.2 gpm/8.3 L/min
5 lb (2.4 kg)
Chrome (002)
286
Stainless Steel (075)
370
0
Colony® PRO Single-Handle Pull-Out Dual Spray Kitchen Faucet 1.5 gpm/5.7 L/min
7 lb (3.4 kg)
Chrome
310
Models marked with * are discontinued, but product may still be available while supplies last.
Didn't find the PDF or file you were looking for? Reach out to our team via our
Contact Form.
There are no design files currently available for this product
3D Objects are not currently available for this product
