Atrio® New

Single Hole Single-Handle L-Size Bathroom Faucet 1.2 GPM

The Atrio Faucet Collection is the ultimate fusion of sophisticated design and precision performance you’ve come to expect from GROHE. Engineered to meet the demands of every bathroom Blueprint, Atrio offers extensive style options from wideset to wall mount lavatory faucets, each ensuring years of unequaled beauty and unrivaled satisfaction

Brushed Nickel 23828EN3 DISCONTINUED   Substitution Available (24350EN0)
List Price: $690.00
ADA Compliant Cal Green CEC Certified LIXIL Select Water Efficient WaterSense
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Single hole installation
  • GROHE SilkMove 1.1" (28 mm) ceramic cartridge
  • Quick installation system
  • Swivel tubular C-spout with flow control
  • Stop limiter
  • Push-open 1 1/4" (32mm) waste set
  • Stainless steel flex lines
  • Flow rate: 1.2 gpm (4.5 l/min)
  • Energy Policy Act of 1992
  • NSF 61,ASME A112.18.1/CSA B125.1,US Federal and State material regulations,EPA WaterSense
Technical Features
  • GROHE SilkMove
  • GROHE StarLight
  • GROHE EcoJoy
  • 11 7/8" Faucet height
  • 6 9/16" Swivel spout reach
  • 7 15/16" Aerator height
  • Nylon braided flex hoses
  • CALGreen/CEC compliant
  • 1.2gpm (WaterSense)
Nominal Dimensions: 7-9/16 in x 5-1/2 in x 11-7/8 in (192 mm x 140 mm x 302 mm)
Description
Net Weight
SKU
Color
List Price USD
Single Hole Single-Handle L-Size Bathroom Faucet 1.2 GPM
7 lb (3.1 kg)
23828EN3 *
Brushed Nickel (GEN)
690
23828003 *
Chrome (G00)
530
Substitutions
Atrio Single Hole Single-Handle L-Size Bathroom Faucet, 1.2 GPM (4.5 L/min)
5 lb (2.4 kg)
24350EN0
Brushed Nickel
1520


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: GROHE SPA
Cal Green: Yes
Category: Bathroom Faucets
CEC Certified: Yes
Color / Finish: Brushed Nickel
Department of Energy Certified: Yes
Collections: Atrio® New
WaterSense: Yes
Faucet Type: Monoblock
Fitting Connection Size Input: 9.52
Handle Type: Lever
Mount Type: Deck Mount
Number of Handles: 1
Fitting Number of Holes: 1
Spout Height: 7-15/16
Spout Type: High Arc
Gallons Per Minute (min-max): 1.2
Input Connection Type: Compression
Kitchen or Bathroom: Bath
LIXIL Select: Yes
Height: 11-7/8
Length: 7-9/16
Width: 5-1/2
Residential or Commercial: Residential
Subcategory: Monoblock Bathroom Faucets
Warranty: Limited Lifetime Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions

Replacement Parts
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
There are no videos currently available for this product
3D Objects are not currently available for this product
