Features
- Cast Brass Waterway
- Braided Flexible Supply Hoses with 3/8" Compression Connectors
- Indexed (Red/Blue) Metal Lever Handle
- Vandal resistant spray
- Max 0.5gpm/1.9L/min. flow rate
- Drain Options: Metail SpeedConnect Drain, Grid Drain, or Less Drain
- Less Drain, Less Pop-Up Hole
Technical Features
- Water-conserving 0.5 gpm/1.9 L/min pressure-compensating aerator spray
- 47 mm ceramic disc valve cartridge with an adjustable Hot Limit Safety Stop
- Cast brass waterway with flexible supply hoses
- Vandal-resistant non-aerator spray
- Braided flexible supply hoses with 3/8" (10 mm) compression connectors
- Indexed Red/Blue metal lever handle
- Less drain
- Less pop-up hole
Nominal Dimensions: 6-3/4 in x 6-1/16 in x 5-5/8 in (171 mm x 154 mm x 143 mm)
