Features
- Simple and fast one person installation with the innovative Speed Connect drain using less parts and no adjustments required
- Cast brass waterway with “City Shanks” are strong and durable, providing a wobble-free installation
- Adjustable Hot Limit Safety Stop limits the amount of hot water allowed to mix with cold, to reduce the risk of accidental scalding
- Ceramic disc valve cartridge assures a lifetime of drip-free performance
- Lead Free
- ADA Compliant design is easy to use
- Large “Comfort Zone”: Allows easy fine tuning of temperature.
- Simple Installation: Fast and easy one person installation. Faucet drops in from top. Quick spin nuts secure faucet in place.
Technical Features
- 40 mm ceramic disc valve cartridge with an adjustable Hot Limit Safety Stop
- Durable cast brass 1/2" (13 mm) male inlet shanks
- Metal body with color-matched underbody
- Water-conserving 1.2 gpm/4.5 L/min pressure-compensating aerator
- Metal lever handle
- Red/Blue index button
- With plug button
- With pop-up hole and rod, less drain
Nominal Dimensions: 6.3 in x 6 in x 4.7 in (160 mm x 152 mm x 119 mm)
Colony® Soft 4-Inch Centerset Single-Handle Bathroom Faucet 1.2 gpm/4.5 L/min With Lever Handle
2 lb (1.1 kg)
Chrome (002)
167
Colony® PRO 4-Inch Centerset Single-Handle Bathroom Faucet 1.2 gpm/4.5 Lpm Less Drain With Lever Handle
2 lb (0.9 kg)
Chrome
171
Colony® Soft 4-Inch Centerset Single-Handle Bathroom Faucet 1.2 gpm/4.5 L/min With Lever Handle
2 lb (1.1 kg)
Chrome (002)
167
Colony® PRO 4-Inch Centerset Single-Handle Bathroom Faucet 1.2 gpm/4.5 Lpm Less Drain With Lever Handle
2 lb (0.9 kg)
Chrome
171
Models marked with * are discontinued, but product may still be available while supplies last.
