Features
- Cast Brass Valve Body: Durable – Quality that will last a lifetime. Ideal material for prolonged contact with water
- Ceramic Disc Valve Cartridge: Assures a lifetime of smooth handle operation and drip-free performance
- Pressure Balancing Valve Cartridge: Maintains constant output temperature in response to changes in hot and cold supply pressure. Diaphragm system engineered to eliminate cross flow and spool "thumping". Avoids failure due to mineral deposits - ideal for use in hard water
- Back-to-Back Capability: Hot and cold can be reversed quickly and easily
- Adjustable Hot Limit Safety Stop: Limits the amount of hot water allowed to mix with cold. Reduces the risk of accidental scalding
- Integral Plaster Guard and Mounting Plate: Plaster guard is designed to protect valve during installation and serve as a mounting plate for thin-wall installations
- No Exposed Screws: Decorative dial plate conceals screws
Technical Features
- Available in Polished Chrome (002)
Nominal Dimensions: 9.8 in x 7.6 in x 7.6 in (249 mm x 193 mm x 193 mm)
There are no additional components to display for this product
Didn't find the PDF or file you were looking for? Reach out to our team via our
Contact Form.
There are no design files currently available for this product
3D Objects are not currently available for this product
