Features
- For 2" x 6" wall installation
- Dual flush – 0.8 gpf and 1.6 gpf (3 L and 6 L)
- For on-the-wall installations or studded walls
- 44" installation height
- 19 7/16" Overall width
- Low noise operation – meets strict European noise (DIN) standards
- Pre-assembled powder coated steel frame with in-wall tank
- Bowl rim height adjustments 15" to 19"
- Pneumatic discharge valve offering: 3 modes of operation: dual flush or start/stop or single flush
- Tank insulated to prevent condensation,1/2" Water supply connection is possible from left, right, back),Drain outlet connections can be set horizontally or vertically,Includes 2 fixing bolts and hardware for the toilet installation,Actuation plate sold separately,CALGreen compliant,For vertical and horizontal use of actuation plate,Maintenance accessible through front
Technical Features
- Dual flush – 0.8gpf and 1.6gpf (3L and 6L)
- Low noise operation – meets strict European noise (DIN) standards
- 19 7/16" Overall width
- Maintenance accessible through front
- Self-supporting, pre-assembled powder coated steel frame with quick and lockable adjustments
- ADA Compliant, Bowl rim height adjustments 15" to 19"
- Pneumatic discharge valve offering 3 modes of operation: dual flush or start/stop or single flush
- Tank insulated to prevent condensation
- 1/2" Water supply connection is possible from four sides of the carrier (top,Left, right, back);Drain outlet connections can be set horizontally or vertically;Includes 2 fixing bolts and installation hardware for the toilet installation;Actuation plate (sold separately);CALGreen compliant;For vertical and horizontal use of actuation plate
- 44" (1.13 m) installation height
Nominal Dimensions: 4 in x 24-5/8 in x 48-7/16 in (102 mm x 625 mm x 1230 mm)
2" x 6" In-Wall Carrier and Tank for Toilet
35 lb (15.8 kg)
Chrome (G00)
593
Rapid SLX 2” x 6” In-Wall Carrier
43 lb (19.3 kg)
No Finish
777
2" x 6" In-Wall Carrier and Tank for Toilet
35 lb (15.8 kg)
Chrome (G00)
593
Rapid SLX 2” x 6” In-Wall Carrier
43 lb (19.3 kg)
No Finish
777
Models marked with * are discontinued, but product may still be available while supplies last.
