Features
- Brass spout & waterway is easy to clean and long-lasting
- Metal lever handles
- Cast brass valve bodies with flexible hose connections for 6"-12" installation
- Braided flexible supply hose with 3/8" compression connectors
- Fast and easy one person installation using an exclusive Speed Connect metal drain which uses fewer parts and no adjustments required to install in less time, even in tight spaces
- ADA Compliant designed lever handle with red & blue indicators
- Lead Free
- Ceramic disc valve cartridge assures a lifetime of drip-free performance
- 1.2 gallons per minute (1.2 gpm/4.5 L/min) maximum flow rate helps to save water
- 20 inch (508 mm) long flexible stainless steel drain cable is pre-assembled to the faucet body
Technical Features
- 1/4-turn washerless ceramic disc valve cartridges
- Water-conserving 1.2 gpm/4.5 L/min pressure-compensating aerator
- Cast brass spout
- Cast brass valve bodies with flexible hose connections for 6"–12" (152–305 mm) installation
- Braided flexible supply hose with 3/8" (10 mm) compression connectors
- Metal lever handles
- Metal Speed Connect® pop-up drain
Nominal Dimensions: 7 in x 13-1/2 in x 6-7/8 in (178 mm x 343 mm x 175 mm)
