Cadet®

Cadet® PRO Two-Piece 1.6 gpf/6.0 Lpf Compact Chair Height Elongated 14-Inch Rough Toilet Less Seat

215FC004.222 DISCONTINUED
List Price: $0.00
ADA Compliant Everclean USMCA Compliant
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • Cadet Flushing System
  • Vitreous china
  • Space saving elongated bowl fits in space of a round front
  • Trade exclusive tank
  • PowerWash® rim scrubs bowl with each flush
  • Chrome finish toilet handle trip lever
  • Robust metal trip lever & metal shank fill valve
  • Includes EZ-Install Tools w/color match bowl caps
  • EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria
  • Limited lifetime warranty on chinaware, limited 5-year warranty on all mechanical parts
Technical Features
  • Includes tank, bowl, and installation kit (seat not included)
  • Bowl Shape: Elongated
  • Rim Height: Chair Height measures 17" (with seat) rim height, ADA compliant
  • Rough-In: 14" (356 mm)
  • Configuration: Two-piece exposed trapway design
  • Flush Rate: 1.60 gpf (6Lpf) single flush low-consumption toilet
  • Made with durable metal components including metal trip lever, arm and brass shank
  • Metal trip-lever, chrome
  • Trapway: 2-1/8" (54 mm) fully glazed
  • PowerWash® Rim Design,EverClean® antimicrobial surface protects against mold, mildew, odor- and stain-causing bacteria,Limited Lifetime Warranty, see warranty page on website for detail
Nominal Dimensions: 30 in x 17-3/8 in x 30-3/8 in (762 mm x 441 mm x 772 mm)
Description
Net Weight
SKU
Color
List Price USD
Cadet® PRO Two-Piece 1.6 gpf/6.0 Lpf Compact Chair Height Elongated 14-Inch Rough Toilet Less Seat
1 lb (0.4 kg)
215FC004.222 *
0
215FC004.020
0
215FC004.021 *
0
Separate Components
Cadet® PRO Compact Chair Height Elongated Bowl
55 lb (25.0 kg)
3517F101.020
0
3517F101.222 *
0
spacer
Cadet® PRO 1.6 gpf/6.0 Lpf 12-Inch Rough Tank
28 lb (12.6 kg)
4188A004.020
0
4188A004.222
0
spacer
Cadet® PRO 12-Inch Rough Toilet Tank Cover
7 lb (3.3 kg)
735172-400.020
0
735172-400.222
0
spacer
Left-Hand Trip Lever
0 lb (0.2 kg)
7381231-200.GN00A
0
Optional Components (Not Included)
Cardiff Slow-Close Elongated Toilet Seat
3 lb (1.5 kg)
5257A65MT.020
0
5257A65MT.222
0


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Front to Back Length: 16-1/2
Bowl Included: Yes
Bowl Shape: Elongated
Brand: American Standard
Chair Height: Chair
Color / Finish: Linen (222)
Department of Energy Certified: Yes
Collections: Cadet®
Everclean: Yes
Fixture Material: Vitreous China
Flush Technology: Gravity Fed
Flush Valve Size: 3
Flusing Type: Single Flush
Gallons Per Flush (min-max): 1.6 GPF
MAP Performance Rating: 1000
Number of Flush Valves: 1
Height: 30-3/8
Length: 30
Length: 30
Width: 17-3/8
Residential or Commercial: Residential
Rough In Size: 14
Rough In Valve Included: Yes
Tank Included: Yes
Trip Lever Location: Left Front
Toilet Water Efficiency: Hight Efficiency Toilet
Toilet Mount Type: Floor Mount
Trapway Diameter: 2-1/8
Toilet Type: Two Piece
USMCA Compliant: Yes
Warranty: 5 Year Limited Warranty
Download All Supporting Documents

Specification Sheet

Installation Instructions

Installation Instructions

Replacement Parts
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
2D CAD Files
.dwg icon 2D CAD File
REVIT Files
.rfa icon REVIT File
3D Objects are not currently available for this product
