Manual Diaphragm FV

Ultima Manual Toilet Flush Valve, Diaphragm-Type, 1.6 gpf/6.0 Lpf, 27-Inch Rough-In

6147162.002 DISCONTINUED
List Price: $0.00
ADA Compliant
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • For flushometer bowls with 1-1/2-inch (38 mm) exposed top spud
  • Exclusive DynaClean® self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • EvoLast® premium chlorine- and chloramine-resistant diaphragm material resists premature deterioration and failure
  • ADA-compliant non-hold open handle provides automatic shut-off after every flush
  • Proprietary brass alloy resists dezincification
  • High back pressure vacuum breaker helps prevent dripping
  • Can be install left- or right-handed
  • 27" (686 mm) rough-in. Pipe can be cut during installation.
Technical Features
  • For flushometer bowls with 1-1/2-inch (38 mm) exposed top spud
  • Exclusive DynaClean® self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • EvoLast® premium chlorine- and chloramine-resistant diaphragm material resists premature deterioration and failure
  • ADA-compliant non-hold open handle provides automatic shut-off after every flush
  • Proprietary brass alloy resists dezincification
  • High back pressure vacuum breaker helps prevent dripping
  • Can be install left- or right-handed
  • 27" (686 mm) rough-in. Pipe can be cut during installation.
Nominal Dimensions: 6-13/16 in x 15-1/16 in x 30-1/16 in (173 mm x 383 mm x 764 mm)
There are no additional components to display for this product
Download Specification Sheet
ADA Compliant: Yes
Barrier Free: Yes
Brand: American Standard
Color / Finish: Chrome (002)
Department of Energy Certified: Yes
Collections: Manual Diaphragm FV
Fitting Connection Size Input: 38.10
Fitting Material: Brass
Gallons Per Flush (min-max): 1.6 GPF
Input Connection Type: NPT (National Pipe Tapered Threads)
Number of Output Valves: 1
Output Connection Type: NPT (National Pipe Tapered Threads)
Height: 30-1/16
Length: 6-13/16
Width: 15-1/16
Residential or Commercial: Commercial
Valve Input Diameter: 1
Valve Output Diameter: 1-1/4
Download All Supporting Documents

Specification Sheet

Installation Instructions

Replacement Parts

Environmental Product Declaration
