Atrio® New

Single Hole Two-Handle M-Size Bathroom Faucet 1.2 GPM

21031003 DISCONTINUED   Substitution Available (21148000)
List Price: $0.00
Cal Green CEC Certified Water Efficient WaterSense
Items REQUIRED for Install
Features Components Specifications Supporting Files Design Files 3D AR Viewer Videos
Features
  • GROHE SilkMove ceramic cartridge
  • Swivel tubular spout with flow control and stop limiter
  • 1/2" (13mm) ceramic cartridge (90° turn)
  • Push-open 1 1/4" (32mm) waste set
  • High spout
  • Stainless steel flex lines
  • Quick installation system
  • Less handles – order (18 026) or (18 027) (sold separately)
  • Flow rate: 1.2 gpm (4.5 l/min)
  • Energy Policy Act of 1992,NSF 61,ASME A112.18.1/CSA B125.1,US Federal and State material regulations
Technical Features
  • GROHE SilkMove
  • GROHE StarLight
  • GROHE EcoJoy
  • 9 3/16" Faucet height
  • 4 15/16" Spout reach
  • 6 7/16" Aerator height
  • Solid brass body
  • Nylon braided flex hoses
  • Less handles – order (18 026) or (18 027) handles (sold separately)
  • CALGreen/CEC compliant,1.2gpm (WaterSense)
Nominal Dimensions: 5-3/4 in x 5-7/8 in x 5-9/16 in (146 mm x 149 mm x 141 mm)
Description
Net Weight
SKU
Color
List Price USD
Single Hole Two-Handle M-Size Bathroom Faucet 1.2 GPM
6 lb (2.7 kg)
21031003 *
0
21031EN3 *
0
Required Components (Not Included)
Cross Handles (Pair)
1 lb (0.3 kg)
18026003 *
0
spacer
Lever Handles (Pair)
1 lb (0.3 kg)
18027003 *
0
Substitutions
Atrio Single Hole Two-Handle M-Size Bathroom Faucet without Handles, 1.2 GPM (4.5 L/min)
0 lb (0.0 kg)
21148000
0


Models marked with * are discontinued, but product may still be available while supplies last.
Download Specification Sheet
Brand: GROHE
Cal Green: Yes
CEC Certified: Yes
Color / Finish: Chrome (G00)
Department of Energy Certified: Yes
Collections: Atrio® New
WaterSense: Yes
Faucet Type: Monoblock
Fitting Connection Size Input: 9.52
Handle Type: Not Included
Mount Type: Deck Mount
Fitting Number of Holes: 1
Spout Height: 3-11/16
Spout Type: Mid Arc
Gallons Per Minute (min-max): 1.2
Input Connection Type: Compression
Kitchen or Bathroom: Bath
Height: 5-9/16
Length: 5-3/4
Width: 5-7/8
Residential or Commercial: Residential
Warranty: Limited Lifetime Warranty
Water Efficient: Yes
Download All Supporting Documents

Specification Sheet

Installation Instructions

Replacement Parts
Didn't find the PDF or file you were looking for? Reach out to our team via our Contact Form.
Download All Design Files
There are no videos currently available for this product
3D Objects are not currently available for this product
